1998 Jeep Wrangler TJ, 5.3 LS, TH400, locked D60s, 42" Pitbulls



Graham, WA


Year, Make, Model

1998 Jeep Wrangler TJ






Chevy 5.3L LS


Gas, EFI



automatic, TH400

Transfer Case

Dana 300, 4:1, twin stick

Front Axle

Chevy Dana 60, 5.13, Detroit Locker, 35 spline chromoly stubs

Rear Axle

Dana 60, 5.13, Yukon Grizzly Air Locker, chromoly shafts

Suspension and Steering

Front Suspension

Triangulated 4 link, Fox 2.5" Air Shocks

Rear Suspension

Triangulated 4 link, Fox 2.0" Air Shocks


full hydro, behind the axle

Tires and Wheels


42" Pitbull Rockers


32 bolt beadlocks



Smittybilt XRC 9500

1998 Jeep Wrangler TJ

5.3L LS swap

  • Texas speed cam
  • BTR valve springs
  • Chromoly pushrods
  • Bosch 044 fuel pump
  • Headers
  • Tuned
  • New radiator, tranny cooler, full hydro cooler with fans.

TH 400 transmission

  • B&M ratchet shifter
  • Have a brand new winters shifter set up for reverse shift pattern with no reverse gate.

Dana 300 transfer case with 4 to 1 kit

  • Twin stick

Chevy Dana 60 front Axle

  • 5:13, Detroit, 35 spline chromoly stubs, SOLID drive flanges, full hydro steering ( setup behind the axle ) slick setup.
  • Triangulated 4 link with Fox 2.5 air shocks

Dana 60 rear axle

  • 5:13 Yukon grizzly air locker with ARB compressor mounted inside. Chromoly axles
  • Triangulated 4 link in rear with Fox 2.0 shocks.
  • Back of frame is tube chassis that it tied into the frame and up through the body into the cage.

New 42” pitbull tires on 32 bolt beadlocks

Other miscellaneous stuff Beard seats, harnesses, soft top, RCI Fuel cell, tons of cage work done, tow points front and rear, tube fenders front and rear, Smittybilt XRC 9,500 winch up front. Full doors.

116” Wheelbase

Flat belly with a belly height of 18” on 42’s

Probably missing a few things but that’s the just of it.

Will trade for side by side ( SXS ) or Toy Hauler of equal value.
